Kverneland Exacta CL W PRO
Exacta CL W PRO for accurate spreading in hilly conditions
Highlights
CentreFlow system – smooth acceleration of the fertiliser Highly accurate weighing system including 4 load cells and a reference sensor ISOBUS compatible and AEF certified Sections of 4 metres with Basic Section Control EasySet for quick and easy adjustment ExactLine - border spreading deviceDescription
The perfect partner for accurate spreading in tough field conditions
The Kverneland Exacta-CL W PRO disc spreader has a compact design a maximum hopper volume of 2800 litres for the medium sized market segment. It is the perfect ISOBUS compatible weighing spreader for precise spreading in hilly conditions, especially on the mixed farms. The heavy duty frame with 4 load cells and reference sensor is developed for intensive use of the spreader. It is reliability and performances has already been proved on the Exacta TL spreader.
The Exacta-CL W PRO is fully ISOBUS compatible as a standard, which means easy plug and play with the IsoMatch Tellus GO+ and PRO or any other AEF certified (tractor) terminal. User convenience can be increased with accessories like the IsoMatch Grip, IsoMatch Global and IsoMatch InLine.
Features
- No impact, no fragmentation, no dust: Central release point, smooth acceleration and centrifugal force accelerates fertiliser up to disc speed before it reaches the vane.
- Accurate spreading pattern: A double overlap spreading pattern gives unrivalled accuracy. The 8 vanes per discs are ensuring a continous flow of fertiliser to the field. This is important for high capacity spreading and forward speed.
- Minimal wind influence, maximum tolerance: Flat discs and a horizontal flow of fertiliser give a symmetrical spreading pattern.
- Consistent spreading pattern: Eight vanes per disc, eight sectors per revolution give an equal distribution. Double overlap spreading pattern.
- Guaranteed accuracy on slopes: guaranteed accuracy on slopes. The fertiliser always contacts the vanes at the same point, also on slopes and travels the complete length of the vane.
- Continuous dynamic "online - calibration" with high frequency communication signal.
- Kvernelands unique reference sensor technology: all negative influences are automatically corrected and eliminated, ensuring utmost spreading accuracy even on hill sides. The Kverneland reference sensor gives you absolute accuracy, because every kilo counts!
- Load cells in combination with the unique reference sensor:
- Auto calibrating and continuous weighing system
- Automatic correction on slopes
- Automatic correction of shocks, even on rough terrain
- Automatic speed related dosing system
- No calibration test needed
- Highest accuracy in all conditions: even spreading quality guaranteed! Save costs and increase quality!
- The compact EasySet 'dashboard' gives you considerably simplified accurate setting and adjustment of application rates. Two hydraulically operated metering plates, each with three discharge openings ensure an equal fertiliser flow from the hopper to the spreading discs.
- The development department of Kvernelands spreader R&D team has its own spreader competence centre in order to allow continuous testing throughout the year. All test are carried out according to the strictest international standards and quality requirements.
- The key to accurate spreading is matching fertiliser quality and litre weight with the spreading charts as close as possible. The Kverneland Exacta checklist helps you to ensure consistent accuracy in all field conditions
1. Select fertiliser type
2. Determine granule size and distribution
3. Determine litre weight
- Direct access to the most recent test results at: www.kvernelandspreadingcharts.com or download the spreading charts Application via the App Store or get it on Google Play
- Kverneland offers the ExactLine system or manual/hydraulic border spreading plate for border spreading. The ExactLine can be accurately set for all types of fertiliser and for all working widths. Operation is easy, no need to leave the tractor seat. For the CL GEOSPREAD, HL, TL TLX GEOSPREAD (iDC) models the ExactLine can even be fitted on the left- and right-hand side of the spreader.
- With one-side boundary spreading the tractor is driven approximately 2 metres from the field border.
- With boundary track spreading the tractor is driving in the first tramline and is spreading to the border. The distance to the border is the half of the working width.
- The Border Spreading Indicator (BSI) on the standard weighing spreaders (Exacta CL EW, Exacta CL W PRO, Exacta TL) indicates which border spreading device is active. For the GEOSPREAD machines this is integrated in the electronics and the active device will be displayed on the control terminal in the cab.
Get your yield increased with more sections
To maximise your output and business there is the possibility to get Basic Section Control software on the Exacta-CL EW, Exacta CL W PRO and the Exacta-TL weighing spreader. A simple way to reduce the overdosing on the headland or irregular shaped of fields by increasing the number of sections. On a standard Kverneland disc spreader the working width can be divided into 1 left and 1 right hand side section – to only shut off half of the working width. The principle of Basic Section Control is based on an even number of 4 metre sections. For example when spreading on 24 metres with 6 sections for the Exacta CL EW/CL W PRO or spreading on 36 metres with 8 sections for the TL.
All standard weighing spreaders (without GEOSPREAD) are equipped with one electrical actuator on each spreading disc to control the application rate to provide maximum use of nutrients to the grass or crops. The Basic Section Control software adjusts the dosing system by a GPS positioning system to optimise overlap and coverage with a minimum over and under dosing. This results in a better yield and a reduction of costs. The SPREADERcontrol license is needed to do Basic Section Control.
With the AutosetApp you have always the most up to date settings for your weighing spreader available. The AutosetApp is an App (software application) available on the IsoMatch Tellus PRO or IsoMatch Tellus GO+ terminal. The AutosetApp is standard integrated into the IsoMatch GEOCONTROL software. This App connects the terminal directly with the GEOSPREAD weighing spreader and will automatically adjust the spreader according to the settings entered into the App. The AutosetApp will also work in combination with the CL-EW, W PRO and TL, with the exception being for those spreaders the discharge point (letter setting) still needs to be adjusted manually on the spreader itself.
The Kverneland fertiliser spreader database with the most up to date spreading charts is always available online. The AutosetApp can connect to the fertiliser spreading database in two different ways. You can connect it to the online database via the IsoMatch Wireless WIFI USB adapter or download the most actual database from the website www.kvernelandspreadingcharts.com on an USB stick and upload the database directly into the IsoMatch Tellus PRO or IsoMatch Tellus GO+ terminal.
Technical specifications
Technical specifications
Download brochureExacta CL W PRO |
Exacta CL W PRO 1300 |
Exacta CL W PRO 1800 |
Exacta CL W PRO 2300 |
Exacta CL W PRO 2800 |
Hopper capacity (l) |
1300 |
1800 |
2300 |
2800 |
Filling height (cm) |
113 |
132 |
151 |
170 |
Width (cm) |
245 |
|||
Filling width (cm) |
239 |
|||
Empty weight (kg) |
495 |
520 |
545 |
570 |
Spread width (m) |
10 - 24 (27/33)* |
|||
Output (kg/min) |
10 - 320 |
* Depending on fertiliser type and type of vanes.
